Rental ESAB Warrior Edge 500 DX Synergic Pulse water cooled MIG welder-1
500amp ESAB Warrior Edge DX water cooled pulsed MIG rental welder package - Image 2
500amp ESAB Warrior Edge DX water cooled pulsed MIG rental welder package - Image 3
500amp ESAB Warrior Edge DX water cooled pulsed MIG rental welder package - Image 4

500amp ESAB Warrior Edge DX water cooled pulsed MIG rental welder package

500amp ESAB Warrior Edge DX water cooled pulsed MIG rental welder package

The Warrior Edge DX is the best pulsed MIG welder in the world… by far. We have the UK’s largest rental fleet of the Edge DX in stock, and have never seen results as good when using the pulsed settings on stainless and aluminium. ROOT process is also beyond words and bizarre to witness (crazy how it works). Spectrum will help you get dialed in straight away with the exact Arc Dynamic, volts, amps, and trim settings for any and every material you’re wanting to weld, to the highest standard imaginable.

See spec sheet: ESAB Warrior Edge Dx Pulsed MIG welder

Email about this machine: info@spectrumweldingsupplies.co.uk

Product Description

Water cooled MIG Welder

Trolley with feeder swivel pin.

Robust Feed Pro 4-roll drive wire feeder setup with a set of 1.0 / 1.2mm drive rollers sent as standard (unless stated otherwise). The cusotmer will be asked beofrehand what wire they are wanting to weld with to ensure correct configuration).

Feeder can be setup for 0.8 / 1.0 / 1.2mm / 1.6mm solid MIG wire V-Grove drive rollers.

Feeder can be setup for 1.2 / 1.6mm flux-cored MIG wire with serrated V-K knurled groove drive rollers.

MB501 x 4 or 5 metre water cooled MIG torch (short 3mtr torch available for soft wires).

Torch setup for any wire configuration (1.0 / 1.2mm plastic coated steel liner sent as standard).

Other torch liners available such as: 3 / 4 / 5 metre 1.0 / 1.2 / 1.6mm polyamide Teflon liner for up to 1.6mm flux-cored.

5 / 10 / 15 metre x 70mm² water cooled interconnection (interlink) cables in stock (that connect the power source to the feeder).

5 metre x 600amp screw-type 70mm² earth lead.

15 metre x 70mm² black rubber copper cable 70-95mm² Dinse plug / socket extension leads available upon request.

Want more information? Call us...
01246 205 267 info@spectrumweldingsupplies.co.uk

Additional information

PACKAGE INCLUDES:

  • ESAB Exeor x 4mtr water cooled MIG torch
  • 600amp x 5mtr 70mm² earth lead
  • 5 / 10 / or 15mtr interlink (machine to feeder reach)
  • 2mtr 20bar 6mm ID 3/8th nut argon hose
  • 415v 32amp 5-pin red plug
  • 1.0mm – 1.2mm V-Groove solid MIG wire drive rollers
  • All other drive rollers for any wire in stock for hire

Read about why this is the best MIG Welder for Welding Pipe The Warrior Edge DX is the full-blooded flagship model with every and all feature, including:

  1. Premium pulsed settings for all grades and variations of mild steel, stainless, duplex, inconel 625, 310 chromium nickel, and aluminium.
  2. ROOT process, which is a mind-blowing way to weld pipe root (like Lincoln Electric STT Surface Tension Transfer, but better) or used to bridge prep up to 25mm wide with solid wire on vertical up without blowing through! (yes, it is actually unbelievable, sets instantly, and bites in perfectly on each side of the prep!). Click here to see the back of a ROOT weld, and here to see the front ROOT results in our workshop.
  3. SPEED process, for ultra fast high deposition and low dilution welds, with targeted penetration and vastly reduced heat affected zones (yes, this process literally ticks every box a welder could ever want).
  4. THIN process, which is a fast process for MIG welding super thin stainless. THIN has the ability to replace welding jobs that typically require intricate stainless TIG welding, which can be very slow and unpractical when needing to welds lots of the same parts.
  5. CRAFT and DEEP processes to follow early 2025 (only available on the DX model).
Supply Voltage

415V
Welding Equipment Type

MIG PULSE Welding, MIG Water Cooled
