SPECIFICATIONS:

• Maximum capacity: 1,000kg (refer to load chart)
• Frame type: Fixed height
• Max diameter ‘cylindrical’ capacity @ 90°:  1600mm
• Tilt range: 0-135°
• Table rotation speed: 0.07 – 2 RPM
• Input Voltage: 415V 3-phase
• Amperage load: 14amps (32amp 4-pin or 5-pin plug)
• Safety devices: Up/Down limit switches (Phase sensitive)
• Pendant control: 7m
• Pendant controller: Forward/reverse/stop/e-stop/variable speed
• Foot pedal control: 7m
• Max welding current: 400A @ 60%

NOTE: If it is not tilting, an electrician will need to swap L2 & L3 in the plug to engage the limit switches.

DIMENSIONS:

• Length: 1420mm
• Width: 954mm
• Height: 900mm
• Table diameter: 900mm
• Floor to centre of table: 800mm
• Weight: 800kg
