ESAB Rogue ET 230iP AC/DC air cooled TIG welder

£1,900.00 exc VAT

We’ve weld tested the Rogue ET 230iP AC/DC single-phase welder extensively, and the results are amazing. It’s super easy to achieve super clean aluminium welds, even when welding 5356 and 5556 grade.

We cannot get my head round how mind-blowing the ET 230iP AC/DC digital display is though. Under each setting option it has a description of what it is you’re adjusting and why ie. Balance / Hertz / Wave shapes, and how it’ll affect your weld.

See our ESAB Demo Bus Open Day LinkedIn post, discussing these outstanding new machines.

It’s portable, high quality, professional AC/DC TIG welder with extended parameter options to excel at everyday aluminium, stainless steel and carbon steel welding. An intuitive graphical user interface with a 5-inch colour display brings new functionality for quick and easy adjustments. The machine can tackle a wide range of thicknesses including very thin plates.

Customizable waveshapes (square, soft square, sinusoidal, triangle) enables optimized heat input for high penetration on thicker metals and low distortion on thin sheets. Pulsing capabilities in both DC and AC TIG offer enhanced weld puddle control allowing the welder to further tailor the arc for multiple applications. TIG arc starts are crafted for optimum performance based on selected tungsten electrode diameter and type.

Durable housing design combines robustness and functionality with multiple lift points for easy manoeuvrability in both workshop and field applications.

3 years warranty

Part no. 0479100400

Product Description

PACKAGE INCLUDES:

  • 1 off,  ESAB Rogue ET 230iP AC/DC TIG welder power source
  • 1 off,  Exeor WP17 rigid neck x 4mtr air cooled super-soft light-weight TIG torch c/w Rogue 230 fittings
  • 1 off,  200amp x 5mtr 25mm² earth lead with 35-50mm² Dinse plug
  • 1 off,  2mtr 20bar 6mm ID argon hose c/w 3/8th nut
  • 1 off,  110V or 240V 16amp / 32amp plug available upon request
  • WP17 or 26 longer 8mtr torch available upon request
  • WP17 or 26 flexi neck option available upon request

SPECIFICATIONS:

  • 110V and 240V
  • AC/DC (for aluminium, mild steel & stainless)
  • HF TIG and MMA stick welder
  • Capable of running on 2x 15mtr 110V or 240V (3-core x 4mm²) extension leads
  • Air cooled
  • Portable
  • Pulsed
  • WP17 air cooled torch duty rating on DC: 150amps @ 60% (6 minutes continuous @ 150amps / 4 minutes cool down)
  • WP17 air cooled torch duty rating on AC: 100amps @ 60% (6 minutes continuous @ 100amps / 4 minutes cool down)
  • Rogue 230 welder duty rating on 240V: 230amps @ 30% (3 minutes continuous / 7 minutes cool down)
  • Rogue 230 welder duty rating on 240V: 126amps @ 100% (10 minutes continuous / 10 minutes cool down)
  • Rogue 230 welder duty rating on 110V: 125amps @ 30% (3 minutes continuous / 7 minutes cool down)
  • Rogue 230 welder duty rating on 110V: 68.5amps @ 100% (10 minutes continuous / 10 minutes cool down)
  • Weight: 19kg
Want more information? Call us...
01246 205 267 info@spectrumweldingsupplies.co.uk
Weight 19 kg
Dimensions 46 × 21 × 38 cm
Brand

ESAB

Equipment Type

AC/DC TIG Welding

Cooling system

Air Cooled

Supply Voltage

110V, 240V
