ESAB Renegade ET 210iP Advanced air cooled DC TIG welder

Name: ESAB Renegade ET 210iP Advanced air cooled DC TIG welder
SKU: 0447750890
Price: 2000.00 GBP
Availability: InStock

£2,000.00 exc VAT

The ‘Renegade’ range is ESAB’s heaviest duty and highest build quality range of welders. The light-duty entry level ESAB Rogue range is outstanding, but Renegade welders steal the show.

All components are better quality and made from stronger materials. The Exeor WP17 x 4mtr torch that the 210iP Advanced package comes with is the smallest, flexible, and lightest weight torch we’ve ever seen.

Everything has been considered with this range. This ET 210iP is the ultimate professional, 110/240V single-phase, high-frequency TIG and MMA inverter welding machine. It is designed with industrial-grade IP23 housing, designed to survive, even in the most demanding environments.

At the same time, it’s lightweight ultra portable with multiple lift points and a high-quality carry strap. Renegade ET models also have a built-in, active PFC circuit, which mean they’ll still work with massive voltage drop when on on 3-core x 4mm² 100mtr long extension leads.

This ET 210iP Advanced DC model also comes with a 4.3″ incredible full-colour digital screen. It offers direct user-friendly access to parameter settings, and an intuitive, bright interface which is easy to read from a distance.

Part no. 0447750890

Product Description

PACKAGE INCLUDES:

1 off, ESAB Renegade ET 210iP Advanced DC TIG welder power source
1 off, Exeor WP17 rigid neck x 4mtr or 8mtr air cooled super-soft light-weight TIG torch c/w Renegade 210 fittings
1 off, 200amp x 5mtr 25mm² earth lead with 35-50mm² welder plug
1 off, 2mtr 20bar 6mm ID argon hose c/w 3/8th nut
1 off, 110V or 240V 16amp / 32amp plug available upon request
WP17 or 26 longer 8mtr torch available upon request
WP17 or 26 flexi neck option available upon request

SPECIFICATIONS:

110V and 240V
110V load @ 140amps full power: 20 amps (32amp yellow plug / 5 kVA needed)
240V load @ 200amps full power: 18 amps (32amps blue plug / 10 kVA needed)
DC (for mild steel & stainless)
HF TIG
MMA stick welder with 78 OCV capable of welding 7018 and 6010 electrodes
Capable of running on 3x 15mtr 110V or 240V (3-core x 4mm²) extension leads
Air cooled
Portable
Pulsed
WP17 air cooled torch duty rating on DC: 150amps @ 60% (6 minutes continuous @ 150amps / 4 minutes cool down)
Weight: 11kg

240V Duty @ 210amps: 25% (2.5 minutes continuous / 7.5 minutes cool down)
240V Duty @ 188amps: 60% (6 minutes continuous / 4 minutes cool down)
240V Duty @ 130amps: 100% (10 minutes continuous / 10 minutes cool down)
110V Duty @ 140amps: 25% (2.5 minutes continuous / 7.5 minutes cool down)
110V Duty @ 90amps: 60% (6 minutes continuous / 4 minutes cool down)
110V Duty @ 70amps: 100% (10 minutes continuous / 10 minutes cool down)
